| Specifications |
| System Architecture |
|
| Processer |
Super RISC Processor 400MHz |
| Operating Platform |
Linux 2.6 Kernel or WinCE 6.0 |
| Memory Flash |
256MB expandable with USB flash drive and SD card |
| Memory RAM |
128MB |
| Power supply voltage |
DC 12V± 10% / 1.5A |
| Dimensions (WxHxL) |
193 x 176 x 85mm |
| Weight |
900g |
| Output Media |
|
| Display Size |
5.7§ diagonal |
| Brightness |
400 nits |
| Resolution |
640 x 480 pixels (65,535 colours) |
| Touch Screen |
Resistive type |
| Graphics Supported |
PNG, JPEG, GIF, BMP |
| Audio Supported |
WAV, WMA, MP3 |
| Video Supported |
MPEG-4, H.264 |
| Audio Ports |
High Definition Stereo (16-bit PCM 44.1 KHz) |
| Speakers |
High Quality loudspeakers for superior audio performance |
| Headphone |
3.5 mm standard jack |
| Data Ports |
|
| SD Card Slot |
1 |
| USB 2.0 |
2 (back compartment) & 2 (side compartment) |
| LAN port 10/100 Mb |
1 |
| RS232 |
1 (+5V DC Power) |
| Power Over Ethernet Module |
IEEE 802.3af Optional |
| Entry/Exit Gate control function |
Optional (2-pin conn) |
| Network Interface |
|
| Wired LAN |
Ethernet: 100MB Base-TX/10MB Base-T (802.3)standard on board,Two network LED indicators in the LAN connector |
| Wireless LAN |
802.11 B/G/N 2.4 GHz(Optional) |
| Encryption protocols |
WPA, PSK and WPA Enterprise security |
| Data Inputs |
|
| Scanner possibilities |
1D Omni Directional Laser Scanner / 2D Imager Selectable |
| Symbologies Supported |
Omni Directional Laser Scanner (1D) or 2D Imager (1D and 2D) |
| Scanner adjustable |
The Scanner can be adjusted over an angle of 42°and locked with step of 6° |
| Software and Applications |
|
| Application |
Price Check Application, Built-in web configuration, management and remote package upgrade |
| Color available |
Gray / Red |
| Environmental |
|
| Operating temperature |
0° ~ 40°C (32° ~ 104°F) |
| Storage temperature |
-20° ~ 60°C (-4° ~ 140°F) |
| Humidity |
5% ~ 95% RH (non-condensing) |
