Model Name |
UTOF150 |
Panel Type |
AU 15" LCD Panel |
Active Display Area (mm) |
304.128 (H) x 228.096 (V) |
Pixel Pitch (mm) |
0.297 (H) x 0.297 (V) |
Number of Pixels |
1024 x 768 |
Display color |
16.2M colors |
Contrast Ration |
400 : 1 |
Backlight |
2 CCFL Backlight units |
Luminance |
250 cd/m2 |
View Angle (CR>=10) |
-65 ~ +65 (H) ; -65 ~ +55 (V) |
Response time (Tr+Tf) |
12 ms |
Synchronization Range Horizontal / Vertical |
31.5 ~ 68 KHz / 56 ~ 75 Hz |
Recommended Resolution |
1024 x 768 @ 60Hz, 75Hz |
Signal Connector |
15 pin D-Sub |
Power Adapter |
Universal AC 100V ~ 240V, 50 ~ 60Hz input, 12V DC, 4.0A output, 48 Watt |
Power Consumption |
30 Watt Typical ; Normal operation |
Plug & Play |
VESA DDC 1/2B |
Dimension (mm) |
360x50.2x300 |
Option Touch |
Resistive ; Capacitive |
Video Input |
Option |
Media Player |
Option |
Download Drawing |
|
Specification is subject to change without notice. |
